Resize

Resizes the current image to the given dimensions.

ImageProcessor.Web allows you to scale images both up and down with an excellent quality to size ratio. A maximum width and height can be set in the configuration to help protect you from DoS attacks.

Six different types of resizing methods are available:

  • Pad (default)
  • BoxPad (Added v4.4.0)
  • Crop
  • Min (Added v4.4.0)
  • Max
  • Stretch

Requests are passed thus:

Resize Pad

Passing a single dimension will automatically preserve the aspect ratio of the original image. If the requested aspect ratio is different then the image will be padded to fit. Widths and heights can optionally also be passed as a ratio. You can recolour the background color of the padded area for image types without transparency from the default black.

Pad mode also offers optional anchor positions:

  • center (default)
  • top
  • right
  • bottom
  • left
  • topleft
  • topright
  • bottomleft
  • bottomright
<!--Automatic height based on width-->
http://your-image?width=600
<!--Automatic width based on height-->
http://your-image?height=250
<!--Both dimensions specified-->
http://your-image?width=600&height=250
<!--Both dimensions specified with the image anchored to the top-->
http://your-image?width=600&height=250&anchor=top
<!--Height ratio passed for automatic scaling-->
http://your-image?width=600&heightratio=0.416
<!--Width ratio passed for automatic scaling-->
http://your-image?widthratio=2.4&height=250
<!--Background color added to padded image-->
http://your-image?width=600&height=250&bgcolor=fff


Resize BoxPad

When upscaling an image the image pixels themselves are not resized, rather the image is padded to fit the given dimensions. When downscaling the image is resized using the rules defined by ResizeMode.Pad. You can recolour the background color of the padded area for image types without transparency from the default black.

BoxPad mode also offers optional anchor positions:

  • center (default)
  • top
  • right
  • bottom
  • left
  • topleft
  • topright
  • bottomleft
  • bottomright
<!--Automatic height based on width-->
http://your-image?width=600&mode=boxpad
<!--Automatic width based on height-->
http://your-image?height=250&mode=boxpad
<!--Both dimensions specified-->
http://your-image?width=600&height=250&mode=boxpad
<!--Both dimensions specified with the image anchored to the top-->
http://your-image?width=600&height=250&anchor=top&mode=boxpad
<!--Height ratio passed for automatic scaling-->
http://your-image?width=600&heightratio=0.416&mode=boxpad
<!--Width ratio passed for automatic scaling-->
http://your-image?widthratio=2.4&height=250&mode=boxpad
<!--Background color added to padded image-->
http://your-image?width=600&height=250&mode=boxpad&bgcolor=fff


Resize Crop

Resizes the image to the given dimensions. If the set dimensions do not match the aspect ratio of the original image then the output is cropped to match the new aspect ratio.

Crop mode also offers optional anchor positions:

  • center (default)
  • top
  • right
  • bottom
  • left
  • topleft
  • topright
  • bottomleft
  • bottomright

You may specify a center as a fraction from the top-left corner of the image in y,x format. Fractions are specified as a decimal between 0 and 1. This point will be as close to the center of your crop as possible while keeping the crop within the image

<!--Standard-->
http://your-image?width=300&height=300&mode=crop
<!--Crop anchored to the top-->
http://your-image?width=300&height=300&mode=crop&anchor=top
<!-- Center -->
http://your-image?width=300&height=300&mode=crop&center=0.25,0.30


Resize Min

Resizes the image until the shortest side reaches the set given dimension. This will maintain the aspect ratio of the original image. Upscaling is disabled in this mode and the original image will be returned if attempted.

http://your-image?width=500&height=500&mode=min


Resize Max

Resizes the image to the given dimensions. If the set dimensions do not match the aspect ratio of the original image then the output is resized to the maximum possible value in each direction while aintaining the original aspect ratio.

http://your-image?width=500&height=500&mode=max


Resize Stretch

Resizes the image to the given dimensions. If the set dimensions do not match the aspect ratio of the original image then the output is stretched to match the new aspect ratio.

http://your-image?width=500&height=500&mode=stretch


Examples

Original

original image

Resize Pad

Image resized with padding.

Resize BoxPad

Image resized with padding.

Resize Crop

Image resized with cropping.

Resize Min

Image resized to fit the aspect ratio.

Resize Max

Image resized to fit the aspect ratio.

Resize Stretch

Image stretched to fit the given dimension.
